Cotic Rocket Frame + Drive System

Cotic Rocket Frame + Drive System

£5,999.00

Rocket: full power e-MTB that rides like a Cotic

Read about the ride
“…the Cotic Rocket was easily the best eMTB of the past 12 months.”
Singletrack World, Best eMTB of the Year More from the review
Frame Size

Availability by size

  • C1 Due March 2027
  • C2 Due March 2027
  • C3 Due March 2027
  • C4 Due March 2027
  • C5 Due March 2027
Reserve yours with a £800 deposit

Pay £800 now to reserve your frame. We'll agree your build with you, and the balance is due before dispatch.

Love It Or Your Money Back

Ride it for 30 days. If you don't love it, send it back for a full refund.

How it works

Terms apply

  • Want something different? We can fit almost any part or upgrade. Call 07970 853 531 or email info@cotic.co.uk and we'll help you spec it.
  • We ship to Europe, the USA (framesets), Canada, Australia and New Zealand, with rates shown at checkout.
  • Built and checked before dispatch — front wheel, bars and pedals to fit
  • Available via Cyclescheme, Green Commute Initiative or Cycle Solutions

Make it yours. On this bike you can choose A La Carte custom paint. A La Carte frames are painted to order right here in the UK, just a few miles from Cotic HQ.

Choose your frame colour and decal colour from our list of tried and tested paints, and choose a matte or gloss finish.

  • Custom paint is included in the price of every Rocket.
See the full A La Carte guide and more examples →
Jeht Ember Gloss with White Highlight with Black Graphics
Golfie Green Gloss with White Graphic
Teal Gloss with Crimson Graphics
Copper Orange Matte with Silver Graphics

🔍 Tap any image to enlarge

Choose your build

Compare the builds

Component Frame + Drive System Bronze Gold Platinum
Groupset Build it your way Cues ebike 1x11 Linkglide Drivetrain Shimano Deore XT Mechanical 8200 XTR ebike Di2 Wireless Drivetrain 1x11 Linkglide
Wheels — Halo Ridgeline 2 Mullet 11spd HG Hope Fortus 30SC Reserve Aluminium Mullet Wheels with Swiss DT350 11spd HG hubs
Tyres — WTB 29 Vigilante 2.6 Light High Grip and 275 Trail Boss 2.6 Tough Fast Schwalbe Magic Mary/Albert Ultrasoft Radial TrialPro Maxxis EXO+ Assegai 29x2.5 DHRII 27.5x2.6 MaxxTerra
Chainset — — — —
Seatpost — SDG Tellis V2 31.6 Seatpost 170mm drop SDG Tellis V2 SDG Tellis V2 31.6 Seatpost 170mm drop
Price £5,999.00 £7,599.00 £8,899.00 £11,449.00

Upgrade your build

Add any of these alongside your bike, they'll show as a separate line in your basket. Want something you don't see here? Just get in touch.

Custom paint is included in the price. Choose your frame colour, decal colour and finish from our paint list.

We'll confirm your choices with you before painting.

About the Rocket

That matters more than it sounds. Most e-bikes, however capable or powerful, feel different from a regular mountain bike in ways that are hard to ignore. Heavier. More planted. Less willing to change direction when you ask. The Rocket doesn't feel like that. It feels like you on a great day, stronger, fresher, and more capable, without surrendering the natural rhythm and responsiveness that makes mountain biking worth doing in the first place.

A slim T45 down tube, rather than a drainpipe-sized chunk of metal or carbon, means the Rocket retains genuine chassis flex and feedback. That life, that Cotic feel, is what the steel frame preserves, even with a motor in the mix.

The new Shimano EP810 ebike power system is their top of the range, lightest, most powerful motor, intuitive and natural feeling, and highly configurable. The external battery means the down tube stays slim and responsive, with hot swapping and simple charging, and perfect weight distribution for predictable traction and precise turn-in.

100% of the frame is made and sourced in the UK, at Five Land Bikes in Scotland, with the aluminium swingarm and CNC machined parts from hand picked UK makers. Custom A La Carte paint is included as standard, no separate upgrade needed.

Range and Performance

EP810 brings 650W and up to 100Nm of torque bring as much punch as any rider could want, and the latest adaptive power setting just makes it feel like you on a great day, everywhere, without constantly scrolling power settings. If you opt for integrated Shimano Di2 electric shifting, you have the option of automatic shifting as well, and the Freeshift function that allows you to shift whilst freewheeling, which is incredibly useful.

With the 504Wh battery, 1000-1200m vertical is easily achievable with using low to medium power modes. Up that figure to nearer 1400-1500m using the 630Wh.

Using higher power modes and ripping up steep climbs, you are looking at more like 800m on the 504 and 1000m on the 630.

On easier going terrain the batteries really last a long time. Cy did a ride in rolling countryside with a total of 800m of vertical, 83km travelled on the 630Wh battery, and still had 17% battery left at the end. On the other hand, riding at the Golfie in Scotland, in Boost up the fireroad climbs, we emptied the 504Wh battery in 2.5 hours, but that was still over 1000m vertical.

Read the full story of how we developed the Rocket →

What's included

  • Cotic Rocket Frame
  • Rear Shock
  • Shimano EP810 Drive System and External Battery
  • Front and Rear Thru Axles
  • All Hose Clips and Guides
Features
  • Radical Cotic Longshot geometry, specifically designed for super short 35mm stems, giving incredible steering responsiveness combined with hugely confidence inspiring capability at speed. Proportional C-Sizing brings consistent balance across all sizes.
  • 150mm Rocklink suspension brings traction, fun and interaction via a strong progression rate.
  • Reynolds 853, Cotic exclusive Ovalform top tube and HD seat tube, combined with motorsport-derived T45 down tube, builds a precise, durable and strong front end with beautiful ride feel.
  • 44mm standard head tube designed with external bottom cup for taper steerer compatibility and angleset compatibility.
  • Bespoke, Cotic engineered motor yoke saves nearly 1kg.
  • External battery power system for super quick battery swap, convenient off-bike charging, and multiple battery ride possibilities, leaving the down tube slim for gorgeous steel ride feel.
  • 6082-T6 UK made aluminium swingarm with Syntace X-12 BOOST148 x 12 rear axle and UDH hanger.
  • Mostly external routing with bespoke 3D printed cable management.
  • Cotic exclusive Floating Trunnion shock mount maximises shock life and sensitivity.
  • Enduro MAX and SKF bearings for long life and highest performance.
  • Adaptable geometry: 150mm fork for trail, 160mm fork for enduro.
  • Five sizes, C1 to C5.

Singletrack World: Best eMTB of the Year

“…the Cotic Rocket was easily the best eMTB of the past 12 months.”
Singletrack World, Best eMTB of the Year. Tested with the EP801 motor; the latest Rocket uses the EP810. (opens in a new tab)
“Going from the Rocket back to other ebikes is revelatory.”
Singletrack World (opens in a new tab)
“…the most capable Cotic mountain bike ever…”
Singletrack World (opens in a new tab)
“…the best geometry from Cotic so far in my opinion…”
Singletrack World (opens in a new tab)

Sizing & geometry

C1 162 - 172cm
C2 170 - 178cm
C3 176 - 184cm
C4 182 - 190cm
C5 184 - 195cm
Frame Size C1 C2 C3 C4 C5
Seat Tube (centre-top) 380 407 435 450 465
Top Tube Length (effective) 595 616 632 653 674
Head Angle 64.5° 64.5° 64.5° 64.5° 64.5°
Effective Seat Angle (at 700mm BB-saddle height) 76.5° 76.5° 77° 77° 77°
Effective Seat Angle (at 815mm BB-saddle height) 76.3° 76.3° 76.7° 76.7° 76.7°
Chainstay Length 450 450 456 456 456
BB Drop (from front wheel) 40 40 40 40 40
Head Tube Length 100 110 120 130 140
Reach 444 463 482 501 520
Stack 630 639 648 657 666
Wheelbase 1225 1248 1277 1300 1324
Stem Length 25-45 25-45 25-45 25-45 25-45
Frame Wheel Travel (55mm stroke shock) 150 150 150 150 150
Wheel Size 29in F / 27.5in R 29in F / 27.5in R 29in F / 27.5in R 29in F / 27.5in R 29in F / 27.5in R
Max Rear Tyre Size 27.5 x 2.6" 27.5 x 2.6" 27.5 x 2.6" 27.5 x 2.6" 27.5 x 2.6"
Max Seatpost Insertion 298 316 347 362 377

All measurements static, based on a 150mm travel fork.

Frame Size C1 C2 C3 C4 C5
Seat Tube (centre-top) 380 407 435 450 465
Top Tube Length (effective) 596 617 633 654 675
Head Angle 64° 64° 64° 64° 64°
Effective Seat Angle (at 700mm BB-saddle height) 76° 76° 76.5° 76.5° 76.5°
Effective Seat Angle (at 815mm BB-saddle height) 75.8° 75.8° 76.2° 76.2° 76.2°
Chainstay Length 450 450 456 456 456
BB Drop (from front wheel) 36 36 36 36 36
Head Tube Length 100 110 120 130 140
Reach 438 457 476 495 514
Stack 635 644 653 662 671
Wheelbase 1231 1254 1283 1306 1330
Stem Length 25-45 25-45 25-45 25-45 25-45
Frame Wheel Travel (55mm stroke shock) 150 150 150 150 150
Wheel Size 29in F / 27.5in R 29in F / 27.5in R 29in F / 27.5in R 29in F / 27.5in R 29in F / 27.5in R
Max Rear Tyre Size 27.5 x 2.6" 27.5 x 2.6" 27.5 x 2.6" 27.5 x 2.6" 27.5 x 2.6"
Max Seatpost Insertion 298 316 347 362 377

All measurements static, based on a 160mm travel fork.

Origin

MADE IN BRITAIN

Cotic frames are designed, developed, engineered and tested entirely by us at our base in Chesterfield, on the edge of the Peak District in the UK. Our founder - Cy Turner - is the lead designer and engineer, and our frames are rigorously ride tested by everyone at Cotic and chosen test riders and ambassadors. The Rocket is fully certified and lab tested to EN15194, the safety standard for electrically power assisted cycles.

The Rocket frame is 100% UK made. The skilled guys at Five Land Bikes in Scotland manufacture the front triangle in custom Cotic designed Reynolds 853, T45 and Ventrics high strength steel, and the T45 seatstays, in small batches, to their exacting standards. The aluminium swingarm and CNC machined parts come from hand picked UK makers.

The frames are ED Coated to prevent corrosion, before being painted using tough and durable automotive spec paint by the Five Land guys. After they have completed their painstaking hand finishing process and their rigorous QC, the frame parts undergo further checking by us before assembly in the workshop at our HQ.

Component sizes

For fitting your own parts, or checking compatibility before you buy.

Seatpost diameter
31.6mm. See geometry tables for maximum insertion.
Front Mech
Not applicable, 1x drivetrains only
Fork
Maximum 160mm travel for 29" wheel, 576mm axle-crown (without sag)
Rear Wheel
27.5"/650B wheel. Maximum width 2.6". Maximum diameter 725mm
Bottom Bracket width
N/A, Shimano STEPS ebike
Bottom Bracket thread
N/A, Shimano STEPS ebike
Chainline
52mm Shimano, 34t chainring
Chainguide Mounting
Shimano STEPS
Headset
44mm for taper steerer forks: Hope 2H, Cane Creek ZS44 top/EC44 bottom, or Chris King Inset I7
Rear Hub
Boost148 x 12 bolt through
Rear Axle
Syntace X-12
Rear Mech Hanger
SRAM UDH
Shock
185x55 Trunnion Mount, air or coil shock compatible
Shock Fittings
Trunnion Rocker, 30.0 x M8 frame end
Dropper Post Routing
Internal via down tube port
Rear Brake Mounting
I.S., maximum 203mm diameter rear disc

Frequently asked questions

What is the Cotic Rocket?
The Cotic Rocket is a full power steel e-MTB with 150mm of Rocklink rear travel, mixed wheels and the Shimano EP810 drive system. It is designed to ride like a Cotic: responsive and natural, with the power to go further.
What motor does the Rocket use?
The Shimano EP810, Shimano's top of the range ebike system, with 650W and up to 100Nm of torque.
What battery options are there?
Shimano external batteries in 504Wh and 630Wh sizes. The external battery allows quick swaps and off-bike charging, and keeps the down tube slim.
What range can I expect from the Rocket?
In low to medium power modes, 1000-1200m of climbing is easily achievable on the 504Wh battery, and nearer 1400-1500m on the 630Wh. Using higher power modes on steep climbs, expect more like 800m on the 504Wh and 1000m on the 630Wh.
Why does the Rocket use an external battery?
It keeps the T45 steel down tube slim, which preserves the chassis flex and feedback that give a Cotic its ride feel. It also allows hot swapping, simple charging and good weight distribution.
Where is the Cotic Rocket made?
100% of the Rocket frame is made and sourced in the UK. Five Land Bikes in Scotland manufacture the steel front triangle and T45 seatstays, and the aluminium swingarm and CNC machined parts come from hand picked UK makers. Bikes are assembled at Cotic's HQ.
What frame material is the Rocket made from?
A Reynolds 853 steel front triangle with Cotic's exclusive Ovalform top tube and HD seat tube, a T45 down tube, T45 steel seatstays, and a 6082-T6 aluminium swingarm.
What wheel size does the Rocket use?
A mixed-wheel (mullet) setup: a 29" front wheel and a 27.5" rear wheel, up to 2.6" wide.
What fork travel is the Rocket designed for?
A 150mm fork for trail riding or a 160mm fork for enduro. 160mm is the maximum.
What sizes does the Rocket come in?
Five sizes, C1 to C5, suiting riders from roughly 5ft 4in to 6ft 5in (162cm to 195cm).
Is custom paint available on the Rocket?
Yes. A La Carte custom paint is included as standard on the Rocket, with no separate upgrade needed.
Does the Rocket have automatic shifting?
On builds with integrated Shimano Di2 electric shifting, you have the option of automatic shifting, plus Freeshift, which lets you change gear while freewheeling.
Can the Rocket run a coil shock?
Yes. The frame's 185x55 trunnion mount shock fitting is compatible with both air and coil shocks.
Does the Rocket fit a dropper post?
Yes. It takes a 31.6mm seatpost with internal routing via a down tube port. Maximum insertion for each size is given in the geometry tables.
What headset does the Rocket use?
A 44mm headset for taper steerer forks: Hope 2H, Cane Creek ZS44 top/EC44 bottom, or Chris King Inset I7.
Is the Rocket safety certified?
Yes. The Rocket is certified and lab tested to EN15194, the safety standard for electrically power assisted cycles.
